Roll Up Grilles
Emergency Egress Security Grille
EEG-300
This motorized Roll up Security Grille is designed to works in public areas that need to be secure but to be automatically open in case of an emergency.
Our Aluminum Security Grilles are strong, durable and attractive.
Our model EEG300 Roll Up Security Grille is capable to be connected to the alarm system so it can be open in case of an emergency. It also comes with an emergency bottom to be connected to the alarm system for local activation.
For all that it provides an attractive and functional design that can secure your areas without blocking a way of egress in case of an emergency.
As a Roll up Security Grill it provides all the same benefits, It’s a reliable closure system to safeguard your property with a customized design that can come in straight pattern or brick pattern, in the standard spacers of 9” or customized to an specific measurement (3”,4.5”, 5” up to 18”).
Ideal security system commonly used on public facilities like malls, parking garages, educational buildings and government facilities.
This Security Grille is build with anodized aluminum components, which made this product more durable against the elements, than regular Grilles usually made of aluminum mill components.
We can also offer it to be designed and engineered calculated for High Velocity Hurricane Zones.
A series of horizontal 5/16” galvanized steel rods, covered by anodized aluminum tubes (spacers) and interconnected with anodized aluminum links
Supports curtain and contains counterbalance torsion springs or band spring for assisting operation. Designed at 10,000 cycles, with the option for higher cycles requirements
Roll-formed galvanized steel guides with steel wall angle that support entire door weight and wind loads, while ensuring a smooth operation when opening and closing the door. Optional guides are extruded Anodized Aluminum guides with steel wall angle.
Protective sheet metal (24 gauge steel galvanized) enclosure for the curtain. Optional finishes are powder coat painted and Anodized Aluminum sheet.
3/16” or 1/4" steel plates to support the hood and counterbalance shaft.
Anodized Aluminum angle and Galvanized steel angle reinforces the curtain and contains the locking mechanisms. Optional bottom bar is extruded Anodized Aluminum tube and aluminum “T” bottom bar.
Our Emergency Egress Roll up Grille is designed to be connected to the alarm system so it can be activated in case of an emergency. It is manufactured with strong 5/16" steel rods to provide a solid barrier and it is covered with Anodized Aluminum tube spacers and interconnected with Anodized Aluminum Links that offers a great appearance and more resistance to the elements arranged in the standard 9" x 2.5" straight pattern that can be customized in size or changed to a brick pattern
This door also can be build of Fenestrated slats or be custom painted and installed in different mounting types that allow you easily fit in your space and fulfill your needs.
