Our HIGH PERFORMANCE Roll up Compact Grille is designed to take the less headroom space possible, allowing you to keep the most of your high clear for free circulation. It offers a high speed operation, great performance and longevity. Features a reliable springless roll up grille that provides users a smooth and fast operation without sacrificing security, safety and durability.
The HP Compact Grille is the ideal solution for low openings with limited headroom space, allowing you to take the most out of the existing high.
As a High Performance grille it provides with security and fast operations. It is built with a VFD (Variable Frequency Drive) that manages the grille at a high speed with a soft start and soft stop features to provide a smooth operation.
This grille is capable to run up to 24 inch per second, which is up to 4 times faster than regular Roll up Grilles. This increases your opening productivity by reducing the operation waiting time.
It high speed and reliable operation significantly reduce the time the grille is open, maximizing your area security and increasing traffic speed.
Most important, the High Performance Compact Grille is still a Roll up Grille capable to offer you the same benefits of a standard product, such as customized pattern (straight or brick) and size (9”x2.5” standard), it can be custom painted with powder coat or use different safety sensors, access controls and more.
A series of horizontal 5/16” galvanized steel rods, covered by anodized aluminum tubes (spacers) and interconnected with anodized aluminum links.
Springless barrel supports curtain and is assembled to the motor and the emergency brake.
Extruded Anodized Aluminum guide with steel wall angle that support entire door weight and wind loads, while ensuring a smooth operation when opening and closing the door.
Due to limited headroom space availability, this grille design doesn’t include a hood, to allow the system reach is maximum high capacity. When included the hood is a protective sheet metal (24 gauge steel galvanized) enclosure for the curtain, motor and emergency brake. Optional finishes are powder coat painted and Anodized Aluminum sheet.
3/16” or 1/4" steel plates to support the hood and counterbalance shaft
Anodized Aluminum angle and Galvanized steel angle reinforces the curtain. Optional bottom bar is extruded Anodized Aluminum.
Rolling Door Manufacturing is a leading provider of door solutions for any application. The HP Compact Grille model is ideal for low openings with limited headroom space, with a coiling system designs that requires half the headroom space regular coiling systems demand, it will help you take the most out of your opening high.
At the same time you don’t have to sacrifyce the performance of your door, with high speed operations it will improve the area security and traffic performance.
It can be customized to meet your special project conditions, offering different size of patterns in straight or brick design. With different operation modes with sensors or access controls, and different finishes options like custom colors, let us know what you need and we'll deliver.
