HIGH PERFORMANCE 1000 ROLL UP DOOR

The HP1000 HIGH PERFORMANCE 1000 Roll up Door is our product designed to work for the longest cycle life: 1,000,000 CYCLES. Additionally it works at a high speed to offer the best performance a Roll up Door can offer. It features a reliable springless roll up door that provide users a smooth and fast operation without sacrificing security, safety and durability.

Watch video

HP Roll Up Doors

High Performance 1000.      Model HP1000

The HP1000 Roll up Door is the more appropriated door for openings where security, fast operations or climate control are critical. Built with a VFD (Variable Frequency Drive) that manages the door at a high speed with a soft start and soft stop features to provide a smooth operation.

The door is capable to run up to 24 inch per second, which is up to 4 times faster than regular Roll up Doors. This increases your opening productivity by reducing the operation waiting time.

It high speed and reliable operation significantly reduce the time the opening is open, maximizing your area security and minimizing the time of air exchange and exposition to the elements.

Most important, the High Performance 1000 is still a Roll up Door capable to offer you the same benefits of a standard Roll up Door, such as Wind Rating capability, different finishes and fenestrations, safety sensors, access controls and more.


Get a Free Quote!

Components

A series of interlocking 20 gauge galvanized steel flat slats fitted with windlocks (designed to meet required wind loads) or endlocks. A variety of finishes available include: galvanized steel, white finish, grey finish, powder-coated paint, anodized aluminum and stainless steel.

Springless barrel supports curtain and is assembled to the motor and emergency brake.

Three-angle structural steel guides that support entire door weight and wind loads, fitted with wear strips to reduce friction while ensuring a smooth operation.

Protective sheet metal (24 gauge steel galvanized) enclosure for the curtain, motor and emergency brake.

 1/4” steel plates to support the hood and counterbalance shaft.

Galvanized steel double angle with a protective weather-strip reinforces the curtain.

Security Grille Door

Benefits

Rolling Door Manufacturing is a leading provider of door solutions for any application. The HP1000 model is designed to last longer and for openings that require high speed operations, whether is for security reasons, to improve traffic performance or to reduce air filtration. It also can be customized to meet your special project conditions, offering different operation modes with sensors or access controls, and offering different finishes options like fenestrations and custom colors, let us know what you need and we'll deliver.

We are one of the highest quality Rolling Door manufactures in the US marketGet a Free Quote!

Made in USA
  1. HIGH SPEED OPERATION – Featuring a soft start and soft stop it will provide a smooth operation that will improve your productivity, reinforce your security and decrease the air exchange.
  2. WIND RATED CAPABLE - Our HP1000-WR can be offered as a Wind Rated product, this door model are laboratory tested and certified by the State of Florida and Miami Dade County to withstand high velocity hurricane winds and impact from debris. (Wind load designs up to ± 70 P.S.F.).
  3. LONGEVITY – Designed for 1,000,000 cycles and offered with a 5 years limited warranty, the HP1000 is built to last the longest.
  4. RELIABLE PROTECTION - Provides reliable protection against robbery and vandalism, offering a high range of locking mechanisms with strong structural angle guides and curtain.
  5. LOW TO NO-MAINTENANCE COST! - Parts are built for heavy duty use and are tested to perform in the toughest environments with very low maintenance required.
  6. COMMERCIAL AND INDUSTRIAL USE - Ideal for Police station, Fire station, parking garages, warehouses, loading docks, stores, and many other types of applications.
  7. CUSTOM BUILT - Each door is custom built to exact opening size requirements and applications.
  8. SPACE OPTIMIZATION - Convenient space saving design, door coils upward without taking away useable space.ving design, door coils upward without taking away usable space.

Make your project unique

As a Rolling Door Manufacturer with over 20 years in the market, we can meet any requirement. Contact us!

Customize your Project

Configure your project completely adapted to all your specific needs. Special designs, finish, combinations, fenestrations, specific performance and more. You can contact us without any compromise.

+1 (305)-599.9977

Fast and reliable support

We develop and provide customized shop-drawings, products data, estimates and manufacturing processes in record time. Consult us.

Opening Hours

Please write your request and a sales representative will be contacting you shortly.

On Message feel free to include door quantities, desired clear opening width and height, door model, operation type (manual or electric), job location and as any other feature or details you are specifically looking for.
